Modular thermal storage in shipping container frames – built for real work.

BrineCell delivers complete, skid‑mounted thermal storage systems inside 20 or 40 ft open container frames. Choose the tank material that fits your climate and budget.

TWO MATERIAL OPTIONS

• Stainless steel tanks – For brine systems in freezing climates or higher temperatures (up to 75°C). Corrosion‑resistant, long life, industrial grade.
• HDPE tanks – For plain water systems in mild climates. More affordable, lightweight, chemically inert. Perfect for low‑ to medium‑temperature storage.

CONTAINER SIZES

• 20 ft frame – Ideal for smaller greenhouses, workshops, or distributed storage.
• 40 ft frame – Larger capacity for industrial process heat, district heating, or central storage.

WHAT’S INCLUDED IN EVERY BRINECELL UNIT

All our systems are manufactured in‑house (Netherlands, Spain, Canada) and come fully integrated:

• Stainless steel or HDPE tank on a heavy‑duty skid
• Filters and centrifuges for clean operation
• Electrical control cabinets (besturingskasten) for automatic function
• Plug‑and‑play connections for heating elements, pumps, and heat exchangers

TECHNICAL SPECIFICATIONS (STANDARD)

• Maximum storage temperature: 75°C (covers 80% of thermal storage needs)
• Usable temperature drop: 30–40°C
• Typical usable energy: 90–100 kWh per 1,000 liters (water)
• Fully vented, atmospheric pressure – safe and simple

READY TO SHIP. READY TO SCALE.

Every BrineCell is built on a skid inside an ISO container frame. Forklift it onto a truck, deliver it anywhere, connect your heat source and load – and start storing energy.

Contact us for a quote – tell us your climate, your heat source, and your required temperature.
